Main parameter

1) Max. 4 Axis;2-4 Axis linear interpolation,any 2 axis circular interpolation;

2) 7 opto isolated digital outputs,8 opto isolated digital inputs;

3) Support every Input and output port definition by users.

4) The controller need 2 power supply,one power supply is for system power,one is for input and output ports power.Both input power is 24V,2A.

5) Open-collector output, Max. output current is 500mA,can power the relay directly;

6) Differential Pulse and direction output signal,Max. 500Khz per axis;

7) Spindle Control: 3 I/O ports control 8 different speeds(3 lines 8 speeds),1 I/O control the Start/Stop;

8) The System Support standard G-code.Also Support the popular CAD/CAM software,such as ArtCam,MasterCam,ProE and so on.

9) USB flash disk support for G code file input;

10) The control system can preview the process path before machining,and it makes the system more steady,working smoothy and precise;

11) Acceleration/Deceleration Mode: S curve;

12) Support un-limited size file for machining;

13) Manual/Automatic machining function;

14) Support the operation to Start a G code from a specific line;

15) Support for “Power Cut” recovery. Data is automatically saved;

16) Support time-lock function;

17) Support 4 kinds operation rights:visitor,operator,admin,super admin;
